BMK6-1000-CC-T1-SF5 Dynamic Hydraulic Motor Charlynn 6000 Series motor
Model number: BMK6-1000-CC-T1-SF5
Replace Char-lynn motor 6000 Series
Displacement: 1000CC
Flange: 4-Φ14.2 Wheel-flange Φ184.12,Pilot 139.7
Shaft: Cone-shaft 1:8 Φ45,parallel key 1.13X11.13X31.75
Port:1-5/16-12UNF
Drain port: 7/16-20 UNF
Paint: BLACK
Main Specification
| Type |
| BMK6 200 | BMK6 250 | BMK6 315 | BMK6 400 | BMK6 500 | BMK6 630 | BMK6 800 | BMK6 1000 |
Geometric displacement
(cm3 /rev.) |
| 195.6 | 246.1 | 311.6 | 391.3 | 490.8 | 623 | 802.4 | 981.6 |
| Main speed(rpm) | cont. | 765 | 610 | 480 | 382 | 304 | 240 | 186 | 152 |
| int. | 865 | 830 | 690 | 570 | 455 | 360 | 280 | 230 |
| Max torque N.M | cont. | 565 | 710 | 920 | 1160 | 1445 | 1480 | 1580 | 1675 |
| int. | 840 | 1080 | 1325 | 1625 | 1880 | 1890 | 1880 | 1860 |
| Max pressure drop (Mpa) | cont. | 20 | 20 | 20 | 20 | 20 | 17.5 | 14 | 14 |
| int. | 30 | 30 | 30 | 30 | 27.5 | 22.5 | 15.5 | 14 |
| Weight (kg) |
| 26.3 | 26.8 | 27.3 | 28 | 28.8 | 29.6 | 30.5 | 32 |
In the vast world of hydraulic system, orbital hydraulic motor occupies an irreplaceable position with its unique charm and powerful adaptability. With its compact structure, excellent low-speed and high-torque output, flexible installation and excellent start-stop commutation performance, it has become the ideal power source for realizing reliable and efficient rotary motion in many mechanical equipments.
From the point of view of functional characteristics, orbital hydraulic motor has a strong low-speed high torque output capability, even at low speed conditions, it can still output stable and strong torque to meet the demand of heavy-duty equipment operation. At the same time, it has a wide range of speed adjustment and can realize stepless speed regulation, which can flexibly adjust the running speed according to different operating scenarios. In addition, the compact size and light weight of the motor, compared with other hydraulic motors with the same torque, has a greater advantage in space layout, which greatly reduces the difficulty of installation and maintenance of the equipment; and with the characteristics of small rotational inertia, it is able to respond quickly to the command of starting, stopping and reversing, which effectively improves the working efficiency and maneuverability of the equipment.
In the field of agricultural machinery, orbital hydraulic motor is widely used in combine harvesters, tractors and other equipment. In combine harvesters, orbital hydraulic motor is essential for stabilizing the movement of the cutting table and unloading the grain tank, as well as the hydraulic suspension system and drive axle of tractors. It helps these equipments to accurately and efficiently complete various operations in the complex farmland environment, whether it is harvesting, conveying or threshing, to ensure smooth and stable movements, and to enhance the efficiency of agricultural production.
In industrial production, orbital hydraulic motor excels in material conveying and mixing equipment. In the mixing tanks of food and chemical industries, orbital hydraulic motor drives the mixing paddles to rotate at a suitable speed with stable torque output to ensure that the materials are fully mixed and the quality of the products is uniform. In material conveying, such as belt conveyor, screw conveyor and other equipments, it can flexibly adjust the rotational speed according to the type and weight of the conveyed materials to realize continuous and stable material conveying and ensure the efficient operation of the production line.
In the field of construction machinery, excavators, loaders, cranes and other equipments also rely on orbital hydraulic motor, which provides power support for the lifting and lowering of the boom, telescoping of the bucket and turning of the bucket of excavators, lifting and unloading of loaders, as well as luffing and slewing of the boom of cranes, etc. Its powerful torque output and flexible speed regulation allow these heavy equipments to perform various difficult operations accurately and efficiently under complicated working conditions, and play a key role in infrastructure construction and mining. Its strong torque output and flexible speed regulation enable these heavy equipment to accurately and efficiently complete various difficult operations under complex working conditions, playing a key role in infrastructure construction, mining and other projects.
With the continuous development of industrial technology, orbital hydraulic motor, by virtue of its excellent function and wide applicability, continues to inject strong power into the machinery and equipment of various industries, and in the future will also show its unique value in more innovative equipment and advanced technology, to promote the continuous development of the industry.
